The following table shows the database specific support in DbVisualizer for {{ curDB.name }} organized per database object type.

• Object Type - show what object types are listed in the Databases tab
• Actions - show what actions are available for the object type
• Viewers - show what viewers are available for the object type

Object Type	Actions	Viewers
Schemas		Schemas
Schema	Export Schema[1], String Search	References, Tables
Tables	Create Table[1], Import Table Data[1]	References, Table Comments, Tables
Table	Alter Table[1], Create Trigger, Export Table[1], Import Table Data[1], Script: Script Table, Analyze Table[2], Comment Table, Copy Table, Create Index, Drop Table, Empty Table, Grant Privilege, Rename Table	Navigator[1], References, Data, Columns, Columns Comment, Constraints, DDL with Storage[4], DDL[3][1], Dependencies, Grants, Indexes, Info, Primary Key, Row Count, Row Id, Triggers
Columns		Columns
Column	Comment Column	Column
Constraints		Constraints
Constraint		Columns, DDL[4], Info
Column	Comment Column	Column
RefConstraints		Constraints
RefConstraint		Columns, DDL[4], Info
Column	Comment Column	Column
Indexes		Indexes
Index	Script: Script Index, Compute Statistics for Index, Drop Index, Rebuild Index, Rename Index	Columns, DDL with Storage[4], DDL[1], Index
Column	Comment Column	Column
IndexPartitions		Partitions
IndexPartition		Info, Sub-Partitions
IndexSubPartition		Info
Triggers		Triggers
Trigger	Export Trigger[1], Compile Trigger, Disable Trigger, Drop Trigger, Enable Trigger, Rename Trigger	Trigger Editor[1], Info
Partitions		Partitions
Partition		Info, Sub-Partitions
SubPartition		Info
GlobalTempTables	Create Table[1], Import Table Data[1]	Tables
TempTable	Alter Table[1], Export Table[1], Import Table Data[1], Script: Script Table, Comment Table, Copy Table, Drop Table, Empty Table, Grant Privilege, Rename Table	Data, Columns, Columns Comment, Constraints, DDL with Storage[4], DDL[3][1], Dependencies, Grants, Indexes, Info, Row Count
Columns		Columns
Column	Comment Column	Column
Views	Create View	View Comments, Views
View	Export View[1], Script: Script View, Comment View, Compile View, Create Trigger, Drop View, Grant Privilege, Rename View	Data, Columns, Columns Comment, DDL[1], Grants, Info, Row Count, Triggers
Columns		Columns
Column	Comment Column	Column
Triggers		Triggers
Trigger	Export Trigger[1], Compile Trigger, Disable Trigger, Drop Trigger, Enable Trigger, Rename Trigger	Trigger Editor[1], Info
Synonyms	Create Synonym	Synonymed Objects, Synonyms
Synonym	Drop Synonym, Rename Synonym	DDL[3][1], Info
Indexes		Indexes
Index	Script: Script Index, Compute Statistics for Index, Drop Index, Rebuild Index, Rename Index	Columns, DDL with Storage[4], DDL[1], Index
Sequences	Create Sequence	Sequences
Sequence	Script: Script Sequence, Drop Sequence, Rename Sequence	DDL[3][1], Info
MaterializedViews		Materialized Views
MaterializedView	Comment Materialized View, Drop Materialized View, Refresh Materialized View	Data, Columns, DDL[4], Grants, Indexes, Info, Row Count, Select SQL
Indexes		Indexes
Index	Script: Script Index, Compute Statistics for Index, Drop Index, Rebuild Index, Rename Index	Columns, DDL with Storage[4], DDL[1], Index
Column	Comment Column	Column
Functions	Create Function	Functions
Function	Export Function[1], Script: Script Function, Compile Function, Drop Function	Function Editor[1], Grants
Procedures	Create Procedure	Procedures
Procedure	Export Procedure[1], Script: Script Procedure, Compile Procedure, Drop Procedure	Procedure Editor[1], Grants
Packages	Create Package	Packages
Package	Export Package[1], Compile Package, Compile Package and Body, Create Package Body, Drop Package and Package Body	Package Specification Editor[1], Grants
PackageBody	Export Package Body[1], Compile Package Body, Drop Package Body	Package Body Editor[1], Grants
PackageBodies	Create Package Body	Package Bodies
PackageBody	Export Package Body[1], Compile Package Body, Drop Package Body	Package Body Editor[1], Grants
JavaSources[5]		Java Sources
JavaSource		Info, Source
JavaClasses[5]		Java Classes
JavaClass		Info
Triggers		Triggers
Trigger	Export Trigger[1], Compile Trigger, Disable Trigger, Drop Trigger, Enable Trigger, Rename Trigger	Trigger Editor[1], Info
ObjectTypes	Create Object Type	Object Types
ObjectType	Export Object Type[1], Compile Object Type, Compile Object Type and Body, Create Object Type Body, Drop Object Type and Type Body	Object Type Editor[1], Attributes, Info, Methods
ObjectTypeBody	Export Object Type Body[1], Compile Object Type Body, Drop Object Type Body	Object Type Editor[1], Attributes, Info, Methods
ObjectTypeBodies	Create Object Type Body	Object Type Bodies
ObjectTypeBody	Export Object Type Body[1], Compile Object Type Body, Drop Object Type Body	Object Type Editor[1], Attributes, Info, Methods
RecycleBin[6]		Recycle Bin
RecycleBinTable	Flashback to Before Drop, Purge from Recycle Bin	Data, Recycle Bin Table
Jobs	Create Job	Jobs
Job	Disable Job, Enable Job, Remove Job, Run Job	Info
Scheduler[7]	Disable Scheduler, Enable Scheduler, Set Scheduler Attribute	Scheduler Global Attributes, Scheduler Jobs Running
SchedulerChains	Create Scheduler Chain	Scheduler Chain Rules, Scheduler Chain Steps, Scheduler Chains, Scheduler Chains Running
SchedulerChain	Analyze Scheduler Chain, Disable Scheduler Chain, Drop Scheduler Chain, Enable Scheduler Chain, Run Scheduler Chain	Scheduler Chain, Scheduler Chain Rules, Scheduler Chain Steps
SchedulerChainRules	Define Scheduler Chain Rule	Scheduler Chain Rules
SchedulerChainRule	Drop Scheduler Chain Rule	Scheduler Chain Rule
SchedulerChainSteps	Define Scheduler Chain Step	Scheduler Chain Steps
SchedulerChainStep	Alter Scheduler Chain Step, Drop Scheduler Chain Step	Scheduler Chain Step
SchedulerJobs	Create Scheduler Job	Scheduler Job Arguments, Scheduler Job Logs, Scheduler Job Run Details, Scheduler Jobs, Scheduler Jobs Running
SchedulerJob	Alter Running Chain, Comment Scheduler Job, Copy Scheduler Job, Disable Scheduler Job, Drop Scheduler Job, Enable Scheduler Job, Modify Scheduler Job, Run Scheduler Job, Stop Scheduler Job	Scheduler Job, Scheduler Job Logs, Scheduler Job Run Details
SchedulerJobArguments	Add Scheduler Job Argument	Scheduler Job Arguments
SchedulerJobArgument	Edit Scheduler Job Argument, Remove Scheduler Job Argument	Scheduler Job Argument
SchedulerPrograms	Create Scheduler Program	Scheduler Program Arguments, Scheduler Programs
SchedulerProgram	Comment Scheduler Program, Disable Scheduler Program, Drop Scheduler Program, Enable Scheduler Program, Modify Scheduler Program	Scheduler Program
SchedulerProgramArguments	Add Scheduler Program Argument	Scheduler Program Arguments
SchedulerProgramArgument	Edit Scheduler Program Argument, Remove Scheduler Program Argument	Scheduler Program Argument
SchedulerSchedules	Create Scheduler Schedule	Scheduler Schedules
SchedulerSchedule	Drop Scheduler Schedule, Evaluate Scheduler Schedule	Scheduler Schedule
SchedulerCredentials[8]	Create Scheduler Credential	Scheduler Credentials
SchedulerCredential	Comment Credential, Drop Scheduler Credential, Modify Credential	Scheduler Credential
DatabaseLinks	Create Database Link	Database Links
DatabaseLink	Drop Database Link, Test Database Link	DDL, Info
InvalidObjects	Compile All	Invalid Objects
Properties		Database Properties[4], Initialization Parameters[4], Session NLS Parameters[4], Session Privileges, Session Roles
DBA		DBA
Users	Create User	Users
User	Change Password, Drop User, Expire Password, Grant Resource Group[3], Lock User, Revoke Resource Consumer Group from User[3], Set Default Resource Group for User[3], Unlock User, Script: Clone User	DDL[9], Info, Resource Groups[3], Roles, System Privileges, Table Privileges, Tablespace Quota
Roles	Create Role	Roles
Role	Drop Role	DDL[4], Info, Roles, System Privileges, Table Privileges, Users
Sessions[10]		Active Sessions, Sessions, Traced Sessions[7]
Session	Disable Trace[7], Enable Trace[7], Kill Session, Kill Session[11]	Active SQL, Plan Data[6], Session, Session Events, Session Wait
Sessions		Active Sessions, Sessions, Traced Sessions[7]
SessionsLocal		Active Sessions, Sessions, Traced Sessions[7]
Session	Disable Trace[7], Enable Trace[7], Kill Session, Kill Session[11]	Active SQL, Plan Data[6], Session, Session Events, Session Wait
SessionsNonLocal		Active Sessions, Sessions, Traced Sessions[7]
SessionNonLocal	Kill Session[8]	Active SQL, Plan Data[6], Session, Session Events, Session Wait
Replication[4]
DataGuard		Archive Dest Status, Archive Destinations, Current db, DG Status, DG config[6]
LogicalStandby		Archive Gap, Logical Standby Events, Unsupported objects
PhysicalStandby		Archive Gap, Managed Standby Procs, Standby Log Files
Streams		Archive Dest Status, Archive Destinations, Current db
StreamsCapture		Capture Parameters, Capture Status, Capture extra Attr[6], Registered Logs
StreamsApply		Apply Latency, Apply Parameters, Apply Status, Capture-Apply Latency
Locks		Blocking Locks, Locks 1, Locks 2
AllRecycleBin[6]		Recycle Bin
AllRecycleBinTable	Flashback to Before Drop, Purge from Recycle Bin	Data, Recycle Bin Table
ResourceManager[3]	Clear Pending Area, Create Pending Area, Generate Monitor SQL, Submit Pending Area, Validate Pending Area	Resource Usage
ResourceConsumerMappings
ResourceConsumerMapping	Add Resource Group Mapping	Resource Consumer Group Mapping
ResourceConsumerMappingValue	Remove From Resource Group Mapping
ResourceConsumerGroups	Create Resource Consumer Group	Resource Consumer Groups
ResourceConsumerGroup	Grant Resource Consumer Group to User, Group default for User, Remove Resource Consumer Group, Revoke Resource Consumer Group from User	Resource Consumer Group, Resource Consumer Group Switch Privs
ResourcePlans	Create Resource Plan	Resource Plans
ResourcePlan	Activate Resource Plan, Remove Resource Plan	Resource Plan, Resource Plan Directives
ResourcePlanDirectives	Add Group to Plan	Resource Plan Directives
ResourcePlanDirective	Modify Resource Directive, Remove Group from Plan	Resource Plan Directive
Storage		ASM Diskgroups[6], All Redo Log Files, Data Files, Directories, Rollback Segments, Tablespaces, Temp Files
ASM[6]		ASM Clients, ASM Diskgroups, Used Client
ASMDiskGroups	Add Disk Group	Details, Usage
ASMDiskGroup	Add Disk to Group, Drop Disk Group, Rebalance Disk Group	ASM Diskgroup, ASM Operation, Files
ASMDisk	Drop Disk	ASM Disk
ASMDisks		ASM Disk
ASMDisk	Drop Disk	ASM Disk
SegmentAdvisor[6]
SegmentAdvisorTasks	Create Task	Segment Advisor Findings, Segment Advisor Logs, Segment Advisor Recommendations, Segment Advisor Tasks
SegmentAdvisorTask	Cancel Task, Delete Task, Execute Task, Interrupt Task, Reset Task	Segment Advisor Findings, Segment Advisor Log, Segment Advisor Recommendations, Segment Advisor Task
SegmentAdvisorObjects	Segment, Tablespace	Segment Advisor Objects
SegmentAdvisorObject	Update Object	Segment Advisor Object
SegmentAdvisorParameters	Set Parameter	Segment Advisor Parameters
SegmentAdvisorParameter		Segment Advisor Parameter
Tablespaces		Datafile IO, Objects, Tablespaces, Usage By User
PermanentTablespaces	Create Tablespace	Datafile IO, Objects, Tablespaces, Usage By User
PermanentTablespace	Add Datafile, Remove Tablespace, Rename Tablespace[6], Tablespace Offline, Tablespace Online, Tablespace Read/Write Mode	DDL[4], Datafile IO, Datafiles, Objects, Tablespace, Usage By User, User Quota
PermanentDataFile	Remove Datafile[6], Rename Datafile, Resize Datafile	Data File, Objects
TemporaryTablespaces[2]		Tablespaces
TemporaryTablespace	Add Datafile	DDL[4], Tablespace, User Quota
TemporaryTempFile	Remove Tempfile[4], Resize Tempfile, Tempfile Offline[4], Tempfile Online[4]	Temp File
UndoTablespaces[4]		Datafile IO, Objects, Tablespaces, Usage By User
UndoTablespace	Add Datafile	DDL[4], Datafile IO, Objects, Tablespace, Usage By User
UndoDataFile	Resize Datafile	Data File, Objects
TablespaceFiles		Data Files, Temp Files
PermanentDataFile	Remove Datafile[6], Rename Datafile, Resize Datafile	Data File, Objects
PermanentTablespace	Add Datafile, Remove Tablespace, Rename Tablespace[6], Tablespace Offline, Tablespace Online, Tablespace Read/Write Mode	DDL[4], Datafile IO, Datafiles, Objects, Tablespace, Usage By User, User Quota
TemporaryTempFile[2]	Remove Tempfile[4], Resize Tempfile, Tempfile Offline[4], Tempfile Online[4]	Temp File
TemporaryTablespace	Add Datafile	DDL[4], Tablespace, User Quota
UndoDataFile[4]	Resize Datafile	Data File, Objects
UndoTablespace	Add Datafile	DDL[4], Datafile IO, Objects, Tablespace, Usage By User
RollbackSegments	Create Rollback Segment	Rollback Segments
RollbackSegment		DDL[4], Rollback Segment
RedoLogs	Create Redo Log Group, Force Log Switch	All Redo Log Files, Redo Log Activity
RedoLog	Add Log File Member	Redo Log
RedoLogMember	Drop Log File Member	Redo Log Member
Directories[4]	Create Directory	Directories
Directory	Drop Directory, Grant Privileges	Directory, Directory Privileges
DirectoryPrivilege	Revoke Privileges
dNFS[8]		Channels, Files, Servers, Stats
Scheduler[7]	Disable Scheduler, Enable Scheduler, Set Scheduler Attribute	Scheduler Global Attributes, Scheduler Jobs Running
SchedulerJobClasses	Create Scheduler Job Class	Scheduler Job Classes
SchedulerJobClass	Drop Scheduler Job Class	Scheduler Job Class
SchedulerWindows	Create Scheduler Window, Purge Window logs	Scheduler Window Details, Scheduler Window Log, Scheduler Windows
SchedulerWindow	Close Scheduler Window, Comment Scheduler Window, Disable Scheduler Window, Drop Scheduler Window, Enable Scheduler Window, Modify Scheduler Window, Open Scheduler Window	Scheduler Window, Scheduler Window Details, Scheduler Window Log
SchedulerWindowGroups	Create Scheduler Window Group	Scheduler Window Groups
SchedulerWindowGroup	Add Window Group Member, Disable Scheduler Window Group, Drop Window Group, Enable Scheduler Window Group	Scheduler Window Group
SchedulerWindowGroupMembers		Scheduler Window Group Members
SchedulerWindowGroupMember	Remove Window Group Member	Scheduler Window
Statistics
AWR[6]	Create Snapshot, Diff Report, Run Report	AWR
InstanceInfo		Instance Info
InstanceSummary		Instance Summary
Latches		Latches
ObjectCount		Object Count
Waits		Waits
SGA	Flush SGA	Object Cache, Poorly Performing SQL's, SGA
[1] DbVisualizer Pro [2] Version 8.1 and later [3] Version 8 and later [4] Version 9 and later [5] If Java Support is installed in database [6] Version 10 and later [7] Version 10.1 and later [8] Version 11 and later [9] Version 7 and later [10] Version 9 and earlier [11] Version 11 and earlier
